17-20 Ford F-150 (3.5 - 4WD) Transfer Case Assembly - N/A - Zumbrota Drivetrain - RTC4466F-1
Details
Transfer Case
RTC4466F-1
BW4466; Electric Shift, Shift motor is not included, 31 Spline Input, 31 Spline Slip Yoke Style Rear Output Shaft, With Torque On Demand, Without Speedo Or Speed Sensor Holes, 4 Position Switch on Dash, 2H, 4 Auto, 4H, 4L, Tag Numbers: FL34-BC, FL34-BD, GL34-BA, GL3Z-B, Hollander Number: 412-00883, Other Numbers: UMT420-8
,15,20,31SPL,412-883,BW4466,CASE,ELEC,F150,INPUT,REAR,RTC,SENS,SHIFT,SLIP,SPEEDO,T,W/O,W/O,YOKE,
Zumbrota Transfer Case BW4466 2015-2020 Ford F-150 Electric Shift 31-Spline
Remanufactured BW4466 Transfer Case, 2017-20 Ford F-150 Raptor, 2019-20 F150 Limited 3.5L VIN G, Electric Shift, 4 Position 4WD Switch, Without Shift Motor
Zumbrota Drivetrain Transfer Cases are rebuilt to unparalleled standards for confidence and satisfaction driving behind the wheel. Our expert craftsmen take pride in restoring each unit to ensure the utmost quality by diligently executing each step. Cases and internal components are thoroughly inspected and tested for signs of wear such as cracks, stripped threads, shaft straightness, gear wear and chain stretch. Zumbrota uses an exclusive Hydro-blast rinse and blasting procedure on internal and external parts, followed by a proprietary shot-enticed deep cleaning. Each unit is fully rebuilt with replacement of all bearings, seals, and viscous couplers. All finished units are thoroughly spun tested for shift-ability and noise. All transfer cases are shipped in high density plastic totes to eliminate damage in transit.
BW4446 Transfer Case
31-Spline
Without Speedo or Sensors
Rear Slip Yoke
Industry leading remanufacturer for hundreds of light duty, medium duty and heavy duty products
- BW4446 Transfer Case
- 31-Spline
- Without Speedo or Sensors
- Rear Slip Yoke
- Industry leading remanufacturer for hundreds of light duty, medium duty & heavy duty products
Housing Color: Aluminum
Housing Material: Aluminum
Rear Output Type: Slip Yoke
Selector Switch Positions: 4 Positions
Shift Operation Type: Electric
Transfer Case Fluid Capacity: 1.5
Transfer Case Fluid Included: No
Transfer Case Fluid Type: Mercon LV ATF
Transfer Case Motor Included: No
Detailed Fitment Results
| Year | Make | Model | Sub Model | Body Type | Drive Type | Bed Length (in) | Fitment Notes |
|---|---|---|---|---|---|---|---|
| 2017 | Ford | F-150 | Raptor | 4WD | BW4466; Electric Shift, Shift motor is not included, With Torque On Demand, 4 Position Switch on Dash, 2H, 4 Auto, 4H, 4L, Tag Numbers: HL3V-AA, HL3V-AB, HL3V-AC, HL3Z-C, Hollander Number: 412-10008 | ||
| 2018 | Ford | F-150 | Raptor | 4WD | BW4466; Electric Shift, Shift motor is not included, With Torque On Demand, 4 Position Switch on Dash, 2H, 4 Auto, 4H, 4L, Tag Numbers: HL3V-AA, HL3V-AB, HL3V-AC, HL3Z-C, Hollander Number: 412-10008 | ||
| 2019 | Ford | F-150 | Raptor / Limited | 4WD | BW4466; Electric Shift, Shift motor is not included, With Torque On Demand, 4 Position Switch on Dash, 2H, 4 Auto, 4H, 4L, Tag Numbers: HL3V-AA, HL3V-AB, HL3V-AC, HL3Z-C, Hollander Number: 412-10008 | ||
| 2020 | Ford | F-150 | Raptor / Limited | 4WD | BW4466; Electric Shift, Shift motor is not included, With Torque On Demand, 4 Position Switch on Dash, 2H, 4 Auto, 4H, 4L, Tag Numbers: HL3V-AA, HL3V-AB, HL3V-AC, HL3Z-C, Hollander Number: 412-10008 |
Fitments
- 2017 Ford F-150 3.5L FLEX
- 2017 Ford F-150 3.5L GAS
- 2018 Ford F-150 3.5L GAS
- 2019 Ford F-150 3.5L GAS
- 2020 Ford F-150 3.5L GAS
